WF Series Electric Winch Pulling Capacity 3,500 lbs. - 12 fpm

The WF Series winches deliver high pulling capacity with a 1700 RPM motor in a lightweight, compact package. Specific models are rated to pull up to 7000 pounds on a single line, and reach maximum speeds up to 120 feet per minute on the full drum.

Additional features and benefits include:

- 1.5 HP, 115/230 Single Phase or 230/460 Three Phase

- See spec sheet for performance data

*Wire rope supplied separately. Contact factory for line pull and wire rope requirements. 800-347-9975 or info@cranedepot.com

Controls:

- Single Speed Handheld - The full voltage handheld pendant control option includes a NEMA 12 rated handheld pendant with 6' lead. The handheld pendant does not provide overload protection.

- Single Speed Low Voltage Controls - Packages include reversing motor starter in a NEMA 4X fiberglass enclosure and a NEMA 4X handheld pendant with UP/DOWN momentary contacts on a 15' lead.

- Variagle Speed Controls - Variable Frequency Drive (VFD) packages include a VFD in a NEMA 4 steel enclosure and a NEMA 4X handheld pendant control with speed potentiometer and UP/DOWN momentary contacts on a 15' lead.
