15 Ton Harrington NERM Series 7.5 FPM 208-230/460v Three Phase

The right equipment. The right support. Fast.

In Stock / Ships Fast

Expert Support Available

Industrial-Grade Equipment

Freight Support Available

List Price $42,014.00 Your Cost $37,811.00

More Information
Manufacture Part Number	NERM150S-L
Brand	Harrington
Estimated Ship Time	1-2 Business Days

Add a new review

Please select required fields below in order to add item(s) to your cart:

CHOOSE VOLTAGE

LIFT

TROLLEY SPEED OPTIONS

CHAIN CONTAINER

MOTORIZED TROLLEY FLANGE WIDTH

Ready to Order?

Buy from Crane Depot with confidence.

Qty

Call Now for Expert Help

Estimated Ship Time: 1-2 Business Days

We make equipment shipping fast, reliable, and hassle-free.

Ships directly from authorized warehouse locations
Nationwide freight shipping available
Shipment tracking is provided after order dispatch
Expedited shipping options available upon request

Chainhoist coordinates every shipment carefully to ensure your equipment arrives safely, securely, and on time.

Product Overview

*Need a Motorized Trolley? - View the NERM Series

*Need a Push Trolley? - View the NERP Series

Harrington's (N)ER enhanced features three phase electric chain hoists are equipped with the latest technology in the market today. All models include a low headroom, lightweight body with a fan-cooled motor, standard thermal motor protection and a count hour meter for preventive maintenance. A secondary mechanical load brake is an additional features on ER models only.

Additional features and benefits include:

- 60 minute, H4 rated motor for the most demanding applications

- "The Guardian" Smart Brake Technology revolutionary DC current motor brake -with electrical failsafe design and 10 year warranty

- Adjustable dual speed via under-the-cover variable frequency drive

- All standard models are UL listed to UL 1340 "Standard for Hoists"

- Completely sealed body suitable for harsh indoor or outdoor environments- IP55 rated

- Plug in pendant and power supply cords save time on set up and maintenance

- Super strength, nickel-plated load chain is corrosion and wear resistant

- 5 or 6 pocket load sheave improves chain life and promotes smooth lifting

Product Resources

Technical Specification

All

1/2

1/4

1/8

1 1/2

2 1/2

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Traversing Speed (ft/min)	Lifting Motor 3 Phase 60 Hz			Traversing Motor 3 Phase 60 Hz			Flange Width Adjustability B (in)		Min** Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)		Weight for Additional One Foot of Lift (lbs)
						Output (Hp)	Rated Current (amps)		Output (Hp)	Rated Current (amps)		Flange Width Adjustability B (in)				Net Weight (lbs)
						Output (Hp)	@208-230V	@460V	Output (Hp)	@208-230V	@460V	Standard	Optional			NER	ER
1/8	(N)ERM001H-L/S	10	8.2	55	L = 40 S = 80	0.75	3.4	1.7	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	4.3 x 1	128	130	0.28
1/4	(N)ERM003S-L/S	10	8.2	36	L = 40 S = 80	0.75	3.4	1.7	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	4.3 x 1	128	130	0.28
1/4	(N)ERM003H-L/S	10	8.2	53	L = 40 S = 80	1.2	4.8	2.5	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	6.0 x 1	148	150	0.54
1/2	(N)ERM005L-L/S	10	8.2	15	L = 40 S = 80	0.75	3.4	1.7	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	6.0 x 1	139	146	0.54
1/2	(N)ERM005S-L/S	10	8.2	29	L = 40 S = 80	1.2	4.8	2.5	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	6.0 x 1	148	150	0.54
1	(N)ERM010L-L/S	10	8.2	14	L = 40 S = 80	1.2	4.8	2.5	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	7.7 x 1	170	176	0.89
1	(N)ERM010S-L/S	10	8.2	28	L = 40 S = 80	2.4	8.6	4.2	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	7.7 x 1	185	185	0.89
1 1/2	(N)ERM015S-L/S	10	8.2	18	L = 40 S = 80	2.4	8.6	4.2	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	31.5†	10.2 x 1	243	254	1.6
2	(N)ERM020C-L/S	10	8.2	7	L = 40 S = 80	1.2	4.8	2.5	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	31.5†	7.7 x 2	214	218	1.8
2	(N)ERM020L-L/S	10	8.2	14	L = 40 S = 80	2.4	8.6	4.2	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	31.5†	10.2 x 1	245	256	1.6
2	(N)ERM020S-L/S	10	8.2	28	L = 40 S = 80	4.7	16.4	7.9	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	31.5†	10.2 x 1	284	282	1.6
2 1/2	(N)ERM025S-L/S	10	8.2	22	L = 40 S = 80	4.7	16.4	7.9	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	39.4	11.2 x 1	333	331	1.9
3	NERM030L-L/S*	10	8.2	16	L = 40 S = 80	4.7	18.3	9.2	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	39.4	12.5 x 1	362	–	2.3
3	(N)ERM030C-L/S	10	9.2	17	L = 40 S = 80	4.7	16.4	7.9	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	39.4	10.2 x 2	340	340	3.2
5	(N)ERM050L-L/S	10	9.2	11	L = 40 S = 80	4.7	16.4	7.9	1.0	5.1	2.5	3.94 to 7.01	7.02 to 7.60 OR 7.61 to 12.00	70.9	11.2 x 2	443	439	3.8

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Traversing Speed (ft/min)	Lifting Motor 3 Phase 60 Hz			Traversing Motor 3 Phase 60 Hz			Flange Width Adjustability B (in)		Min** Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)		Weight for Additional One Foot of Lift (lbs)
						Output (Hp)	Rated Current (amps)		Output (Hp)	Rated Current (amps)		Flange Width Adjustability B (in)				Net Weight (lbs)
						Output (Hp)	@208-230V	@460V	Output (Hp)	@208-230V	@460V	Standard	Optional			NER	ER
1	(N)ERM010L-L/S	10	8.2	14	L = 40 S = 80	1.2	4.8	2.5	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	7.7 x 1	170	176	0.89
1	(N)ERM010S-L/S	10	8.2	28	L = 40 S = 80	2.4	8.6	4.2	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	7.7 x 1	185	185	0.89

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Traversing Speed (ft/min)	Lifting Motor 3 Phase 60 Hz			Traversing Motor 3 Phase 60 Hz			Flange Width Adjustability B (in)		Min** Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)		Weight for Additional One Foot of Lift (lbs)
						Output (Hp)	Rated Current (amps)		Output (Hp)	Rated Current (amps)		Flange Width Adjustability B (in)				Net Weight (lbs)
						Output (Hp)	@208-230V	@460V	Output (Hp)	@208-230V	@460V	Standard	Optional			NER	ER
2	(N)ERM020C-L/S	10	8.2	7	L = 40 S = 80	1.2	4.8	2.5	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	31.5†	7.7 x 2	214	218	1.8
2	(N)ERM020L-L/S	10	8.2	14	L = 40 S = 80	2.4	8.6	4.2	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	31.5†	10.2 x 1	245	256	1.6
2	(N)ERM020S-L/S	10	8.2	28	L = 40 S = 80	4.7	16.4	7.9	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	31.5†	10.2 x 1	284	282	1.6

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Traversing Speed (ft/min)	Lifting Motor 3 Phase 60 Hz			Traversing Motor 3 Phase 60 Hz			Flange Width Adjustability B (in)		Min** Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)		Weight for Additional One Foot of Lift (lbs)
						Output (Hp)	Rated Current (amps)		Output (Hp)	Rated Current (amps)		Flange Width Adjustability B (in)				Net Weight (lbs)
						Output (Hp)	@208-230V	@460V	Output (Hp)	@208-230V	@460V	Standard	Optional			NER	ER
3	NERM030L-L/S*	10	8.2	16	L = 40 S = 80	4.7	18.3	9.2	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	39.4	12.5 x 1	362	–	2.3
3	(N)ERM030C-L/S	10	9.2	17	L = 40 S = 80	4.7	16.4	7.9	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	39.4	10.2 x 2	340	340	3.2

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Traversing Speed (ft/min)	Lifting Motor 3 Phase 60 Hz			Traversing Motor 3 Phase 60 Hz			Flange Width Adjustability B (in)		Min** Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)		Weight for Additional One Foot of Lift (lbs)
						Output (Hp)	Rated Current (amps)		Output (Hp)	Rated Current (amps)		Flange Width Adjustability B (in)				Net Weight (lbs)
						Output (Hp)	@208-230V	@460V	Output (Hp)	@208-230V	@460V	Standard	Optional			NER	ER
5	(N)ERM050L-L/S	10	9.2	11	L = 40 S = 80	4.7	16.4	7.9	1.0	5.1	2.5	3.94 to 7.01	7.02 to 7.60 OR 7.61 to 12.00	70.9	11.2 x 2	443	439	3.8

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Traversing Speed (ft/min)	Lifting Motor 3 Phase 60 Hz			Traversing Motor 3 Phase 60 Hz			Flange Width Adjustability B (in)		Min** Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)		Weight for Additional One Foot of Lift (lbs)
						Output (Hp)	Rated Current (amps)		Output (Hp)	Rated Current (amps)		Flange Width Adjustability B (in)				Net Weight (lbs)
						Output (Hp)	@208-230V	@460V	Output (Hp)	@208-230V	@460V	Standard	Optional			NER	ER
1/2	(N)ERM005L-L/S	10	8.2	15	L = 40 S = 80	0.75	3.4	1.7	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	6.0 x 1	139	146	0.54
1/2	(N)ERM005S-L/S	10	8.2	29	L = 40 S = 80	1.2	4.8	2.5	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	6.0 x 1	148	150	0.54

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Traversing Speed (ft/min)	Lifting Motor 3 Phase 60 Hz			Traversing Motor 3 Phase 60 Hz			Flange Width Adjustability B (in)		Min** Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)		Weight for Additional One Foot of Lift (lbs)
						Output (Hp)	Rated Current (amps)		Output (Hp)	Rated Current (amps)		Flange Width Adjustability B (in)				Net Weight (lbs)
						Output (Hp)	@208-230V	@460V	Output (Hp)	@208-230V	@460V	Standard	Optional			NER	ER
1/4	(N)ERM003S-L/S	10	8.2	36	L = 40 S = 80	0.75	3.4	1.7	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	4.3 x 1	128	130	0.28
1/4	(N)ERM003H-L/S	10	8.2	53	L = 40 S = 80	1.2	4.8	2.5	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	6.0 x 1	148	150	0.54

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Traversing Speed (ft/min)	Lifting Motor 3 Phase 60 Hz			Traversing Motor 3 Phase 60 Hz			Flange Width Adjustability B (in)		Min** Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)		Weight for Additional One Foot of Lift (lbs)
						Output (Hp)	Rated Current (amps)		Output (Hp)	Rated Current (amps)		Flange Width Adjustability B (in)				Net Weight (lbs)
						Output (Hp)	@208-230V	@460V	Output (Hp)	@208-230V	@460V	Standard	Optional			NER	ER
1/8	(N)ERM001H-L/S	10	8.2	55	L = 40 S = 80	0.75	3.4	1.7	0.54	3.2	1.6	2.28 to 5.00	5.01 to 6.02 OR 6.03 to 12.00	31.5**	4.3 x 1	128	130	0.28

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Traversing Speed (ft/min)	Lifting Motor 3 Phase 60 Hz			Traversing Motor 3 Phase 60 Hz			Flange Width Adjustability B (in)		Min** Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)		Weight for Additional One Foot of Lift (lbs)
						Output (Hp)	Rated Current (amps)		Output (Hp)	Rated Current (amps)		Flange Width Adjustability B (in)				Net Weight (lbs)
						Output (Hp)	@208-230V	@460V	Output (Hp)	@208-230V	@460V	Standard	Optional			NER	ER
1 1/2	(N)ERM015S-L/S	10	8.2	18	L = 40 S = 80	2.4	8.6	4.2	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	31.5†	10.2 x 1	243	254	1.6

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Traversing Speed (ft/min)	Lifting Motor 3 Phase 60 Hz			Traversing Motor 3 Phase 60 Hz			Flange Width Adjustability B (in)		Min** Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)		Weight for Additional One Foot of Lift (lbs)
						Output (Hp)	Rated Current (amps)		Output (Hp)	Rated Current (amps)		Flange Width Adjustability B (in)				Net Weight (lbs)
						Output (Hp)	@208-230V	@460V	Output (Hp)	@208-230V	@460V	Standard	Optional			NER	ER
2 1/2	(N)ERM025S-L/S	10	8.2	22	L = 40 S = 80	4.7	16.4	7.9	0.54	3.2	1.6	3.23 to 6.02	6.03 to 7.02 OR 7.03 to 12.00	39.4	11.2 x 1	333	331	1.9
