1/4 Ton Harrington SNERP Series 14 FPM 115/230v Single Phase

The right equipment. The right support. Fast.

In Stock / Ships Fast

Expert Support Available

Industrial-Grade Equipment

Freight Support Available

List Price $4,346.00 Your Cost $3,473.00

More Information
Manufacture Part Number	SNERP003S
Brand	Harrington
Estimated Ship Time	1-2 Business Days

Add a new review

Please select required fields below in order to add item(s) to your cart:

CHOOSE VOLTAGE

LIFT

CHAIN CONTAINER

PUSH TROLLEY FLANGE WIDTH

Ready to Order?

Buy from Crane Depot with confidence.

Qty

Call Now for Expert Help

Estimated Ship Time: 1-2 Business Days

We make equipment shipping fast, reliable, and hassle-free.

Ships directly from authorized warehouse locations
Nationwide freight shipping available
Shipment tracking is provided after order dispatch
Expedited shipping options available upon request

Chainhoist coordinates every shipment carefully to ensure your equipment arrives safely, securely, and on time.

Product Overview

Harrington's SNER electric chain hoists are built for extreme duty applications that require single phase power. A hoist with a 60 minute, H4 duty rated motor is revolutionary and unmatched in a single phase offering. Maintenance friendly features include a unique chain guide, hinged control panel, sealed housing and durable load sheave. For beam travel requirements couple with SMR motorized, PT manual push and GT manual geared trolleys.

Additional features and benefits include:

- SNER, capacities 1/4 Ton through 3 Ton

- 60 minute, H4 rated, fan cooled motor for the most demanding applications

- Pull-rotor electric brake is self-adjusting and virtually maintenance-free

- Ability to accommodate very long lifts

- Compact, low headroom design

-Completely sealed body suitable for harsh indoor or outdoor environments - IP55 rated

-Push Trolley Flange Width for 1/4 Ton : 2.28"-4.00" (Flange Width Extender Options Available)

Product Resources

Technical Specification

All

1/4

1/2

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Lifting Motor 1 Phase 60 Hz			Flange Width Adjustability B (in)		Minimum Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)	Weight for Additional One Foot of Lift (lbs)
					Output (Hp)	Rated Current (amps)
					Output (Hp)	@115V	@230V	Standard	Optional
1/4	SNERP(SNERG)003S	10	7.5	14	0.34	7.7	3.9	2.28 to 4.00 (2.28 to 5.00)	4.01 to 8.00 (5.01 to 8.00) OR 8.01 to 12.00	43.3 (51.2)	5.0 x 1	93 (110)	0.37 (1.0)
1/2	SNERP(SNERG)005L			7	0.34	7.7	3.9		4.01 to 8.00 (5.01 to 8.00) OR 8.01 to 12.00		6.3 x 1	95 (112)	0.57 (1.2)
1/2	SNERP(SNERG)005S			15	0.6	16.9	8.5		4.01 to 8.00 (5.01 to 8.00) OR 8.01 to 12.00		6.3 x 1	115 (135)	0.57 (1.2)
1	SNERP(SNERG)010L			7	0.6	16.9	8.5	2.28 to 5.00	5.01 to 8.00 OR 8.01 to 12.00	51.2	8.0 x 1	130 (141)	0.93 (1.5)
1	SNERP(SNERG)010S			14	8.0 x 1	179 (190)	0.93 (1.5)	2.28 to 5.00	5.01 to 8.00 OR 8.01 to 12.00	51.2
2	SNERP(SNERG)020L			7	1.2	23.9	12.0	3.23 to 6.02	6.03 to 12.00	59.1	10.0 x 1	209 (220)	1.5 (2.2)
3	SNERP(SNERG)030C		8.2	3.5	1.2	23.9	12.0	3.23 to 6.02	6.03 to 12.00	66.9	10.0 x 2	251 (262)	3.1 (3.7)

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Lifting Motor 1 Phase 60 Hz			Flange Width Adjustability B (in)		Minimum Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)	Weight for Additional One Foot of Lift (lbs)
					Output (Hp)	Rated Current (amps)
					Output (Hp)	@115V	@230V	Standard	Optional
1/4	SNERP(SNERG)003S	10	7.5	14	0.34	7.7	3.9	2.28 to 4.00 (2.28 to 5.00)	4.01 to 8.00 (5.01 to 8.00) OR 8.01 to 12.00	43.3 (51.2)	5.0 x 1	93 (110)	0.37 (1.0)

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Lifting Motor 1 Phase 60 Hz			Flange Width Adjustability B (in)		Minimum Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)	Weight for Additional One Foot of Lift (lbs)
					Output (Hp)	Rated Current (amps)
					Output (Hp)	@115V	@230V	Standard	Optional
1/2	SNERP(SNERG)005L	10	7.5	7	0.34	7.7	3.9	2.28 to 4.00 (2.28 to 5.00)	4.01 to 8.00 (5.01 to 8.00) OR 8.01 to 12.00	43.3 (51.2)	6.3 x 1	95 (112)	0.57 (1.2)
1/2	SNERP(SNERG)005S	10	7.5	15	0.34	7.7	3.9	2.28 to 4.00 (2.28 to 5.00)	4.01 to 8.00 (5.01 to 8.00) OR 8.01 to 12.00	43.3 (51.2)	6.3 x 1	115 (135)	0.57 (1.2)

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Lifting Motor 1 Phase 60 Hz			Flange Width Adjustability B (in)		Minimum Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)	Weight for Additional One Foot of Lift (lbs)
					Output (Hp)	Rated Current (amps)
					Output (Hp)	@115V	@230V	Standard	Optional
1	SNERP(SNERG)010L	10	7.5	7	0.6	16.9	8.5	2.28 to 5.00	5.01 to 8.00 OR 8.01 to 12.00	51.2	8.0 x 1	130 (141)	0.93 (1.5)
1	SNERP(SNERG)010S	10	7.5	14	0.6	16.9	8.5	2.28 to 5.00	5.01 to 8.00 OR 8.01 to 12.00	51.2	8.0 x 1	179 (190)	0.93 (1.5)

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Lifting Motor 1 Phase 60 Hz			Flange Width Adjustability B (in)		Minimum Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)	Weight for Additional One Foot of Lift (lbs)
					Output (Hp)	Rated Current (amps)
					Output (Hp)	@115V	@230V	Standard	Optional
2	SNERP(SNERG)020L	10	7.5	7	1.2	23.9	12.0	3.23 to 6.02	6.03 to 12.00	59.1	10.0 x 1	209 (220)	1.5 (2.2)

Cap. (Tons)	Product Code	Std. Lift (ft)	Push Button Cord L (ft)	Lifting Speed (ft/min)	Lifting Motor 1 Phase 60 Hz			Flange Width Adjustability B (in)		Minimum Allow. Radius for Curve (in)	Load Chain Diameter (mm) x Chain Fall Lines	Net Weight (lbs)	Weight for Additional One Foot of Lift (lbs)
					Output (Hp)	Rated Current (amps)
					Output (Hp)	@115V	@230V	Standard	Optional
3	SNERP(SNERG)030C	10	8.2	3.5	1.2	23.9	12.0	3.23 to 6.02	6.03 to 12.00	66.9	10.0 x 2	251 (262)	3.1 (3.7)
